Varan®: sodium-activated bentonite powder for green sand

A selectively mined clay binder that gives green sand better wet tensile and green compressive strength, and holds that strength through the heat.

Molten iron poured into a green-sand mould at a foundry

Description

Varan® is sodium-activated bentonite for green sand moulding, selectively mined for foundry use and made entirely by clay extrusion, a mechanical process that gives uniform behaviour. It takes up water quickly, so preparation time is short, and it improves shakeout. In the system sand it reduces the dead clay percentage and the moisture needed to achieve the moulding properties, and on long-term use less Varan® is consumed.

Used for: Foundry green sand moulding

Other bentonite for process industries: Pellet-Maker™

All Amrfeo products

What goes wrong on site

What you see on site

What this does about it

Scabs and related defects at the mould face.
Higher wet tensile strength in the system sand helps prevent them.
Blow holes in the castings.
Regular use reduces the dead clay in the system sand, and the blow holes with it.
The bond burns out near the metal.
Varan® keeps its strength on exposure to high temperature, which gives a better shakeout.
Mixing runs long before the sand is ready.
It takes up water quickly, so preparation time is short.

Technical properties

  • 0.22 N/cm²Wet tensile strength, minimum
  • 8.0 N/cm²Green compressive strength, minimum
  • 6.0 N/cm²Green compressive strength, calcined to 550 °C, minimum
  • 35 mlFree swelling volume, minimum (ASTM D5890)
  • 380 mg/gMBA value (VDG)
  • 12% maxMoisture

At 5% bentonite addition on AFS 50–60 sand, average values. Green compressive strength is also given after calcining to 550 °C: the bond the sand keeps after the heat.

Packing 25 kg bags, stretch-wrapped on wooden pallets, or 1,300 kg jumbo bags.

Resources

  • Technical data sheetSent to you by email.
    Request
  • Safety data sheetSent to you by email.
    Request

Not sure what your system sand needs?

Send us your sand test report — grain fineness, active clay, compactability, moisture. The technical desk reads it and replies within 1 working day.

Made by us. Checked by others.

Since 1994

A manufacturer, not a trader. Bentonite at Bhuj, polymers at Domjur.

ISO 9001:2015

All our plants are quality management system certified.

Star Export House

Recognised by the Government of India. We ship through Mundra and Kandla.

Own mine, Kutch

The clay in every bag comes from our own reserves in Kutch.

Frequently Asked Questions

What is Varan® used for?

Green sand moulding in iron and steel foundries. It is sodium-activated bentonite, selectively mined for foundry use and made from a 100% clay extrusion process. It takes up water quickly, so preparation time is short.

How much Varan® goes into the sand?

Varan® is specified at 5% bentonite addition with the sand at AFS 50–60. What your own system takes depends on your sand, your castings and your moulding method: finer sand, heavier sections and hotter pours need more. Send us a sand test report and the technical desk will reply.

Does it hold its strength at casting temperature?

Yes. Varan® keeps its strength when exposed to high temperature, which is what green sand needs for a better shakeout.

Why is my sand losing strength though I keep adding bentonite?

Probably because the clay you track is total clay, not active clay. Every pour burns some bentonite into dead clay, which stays as inert fines, so adding more bentonite without removing fines makes the sand heavier and weaker. Regular use of Varan® reduces the dead clay percentage, and less moisture is needed to achieve the moulding properties.

Will it cut what I spend per tonne of good castings?

Compare it on cost per tonne of good castings, not on the price of a bag. On long-term use, consumption of Varan® is considerably reduced; less moisture is needed; and casting blow holes reduce considerably, owing to the reduction of dead clay. Send us a sand test report and we will work it out for your system.

How is Varan® packed?

25 kg bags on wooden pallets, or 1,300 kg jumbo bags: a container takes 26.4 tonnes net in 25 kg bags and 26 tonnes net in jumbo bags. It is mined and processed by us at Bhuj, Kutch, Gujarat, and exported through Mundra and Kandla.

Which test methods and standards apply?

Free swelling is tested to ASTM D5890, and strength and MBA value by the VDG standard, including VDG P69 after heating.

Who supplies Varan®?

Amrfeo Private Limited, a manufacturer since 1994, makes and exports Varan®, supplying buyers across the Gulf, Europe and Asia. The bentonite is mined and processed at our plant at Bhuj, Kutch, Gujarat, under ISO 9001:2015.
